KWIB1811

LIST PRICE $4,295.00

17,700 btuh full featured Iceberg Water-Cooled Portable

General Details
The Model KWIB1811 (nominal 1.5-ton or 17,700 BTU) is the smallest water-cooled unit possible in size and capacity in The Iceberg Series, KwiKool’s Flagship Line of portables. With its full-featured design and high sensible cooling, the KWIB1811 is the perfect solution for cooling small server and IDF rooms. The Iceberg Series is quick and easy with its “plug and play” technology and tops the competition in its small size, big performance and tons of features. From its hi-tech microprocessor controls and self-diagnostics, to the long list of standard features (most of which are not even available in other brands), the Iceberg Series out performs, out lasts, and out features other portables and all at a price that is comparable to the no frills products that are available.

All Iceberg Series KWIB water-cooled units require access to a circulating water system, such as chilled water. Using tap water for water-cooled models is not recommended except for temporary applications.

The KWIB models are equipped with a self-regulating internal water regulating valve, which is rated up to 150 psi. The KWIB1811 runs on a standard 115-volt/20-amp circuit with automatic restart after a power failure. The unit comes with an internal high lift condensate pump and a 5-gallon exterior condensate tank with float activated unit cut off for short term use.

And, KwiKool products are proudly MADE IN AMERICA.

made-in-usa-badge

Cooling Capacity (BTUH)
17,700 btuh (1.5-Ton)
Power Supply
115V- 1Ø   20 Amp Circuit
Dimensions (WxDxH)
16.325×21.75×37.25
Specifications
COOLING CAPACITY
BTU/hr @ 95F at 60% RH17,700 (1.5-Ton)
COMPRESSOR DATA
Compressor TypeHermetic Rotary
Operating Temperatures60-110 F 50%RH
Refrigerant410A
FAN DATA
Evaporator
Fan Type (Centrifugal)Direct Drive
Air Flow (CFM)600/3 Speed
Supply Air DeviceAdjustable Vent
Supply Air Chute Kit (optional)2 - 5" Dia. x 16" Length
Condenser Water Flow Data
Flow Regulating Valve 1/2"NPTAutomatic
Inlet Water 85F-95F Exit (GPM)4.5
Inlet Water 75F-95F Exit (GPM)2.25
Inlet Water 65F-95F Exit (GPM)1.5
Inlet Water 55F-95F Exit (GPM)1.2
ELECTRICAL DATA
Power Supply (Volts) 115/Single Phase
Current Consumption (Amps) 13.6
Power Consumption (kW) 1.4
Maximum Circuit Breaker (Amps) 20
Recommended Breaker Size20
Minimum Circuit Ampacity(Amps) 20
Min./Max. Voltage 105-125
Power Cord Gauge/Length 12AWG/6'
Plug Configuration NEMA 5-20
DIMENSIONAL DATA
Width x Depth x Height (Inches) 16.325" x 21.75" x 37.25"
Weight (Lbs.) 165
Shipping Weight (Lbs.) 215
SAFETY DEVICE DATA
Compressor Overload Internal
Fan Motor Overload Automatic Internal
Evaporator Freeze Protection Hot Gas Bypass
High Pressure Switch Manual
Low Pressure Switch Automatic
Compressor Short Cycle Yes
Automatic Restart Yes
Thermostat Type Microprocessor/Digital
Condensate Pump Overflow Yes
Condensate Tank Overflow Yes
Detail Drawings
KWIB1811DD
Features
  • MADE IN USA
  • 17,700 BTU/H – 1.5 Ton capacity water-cooled
  • Compact yet Powerful
  • Runs on 115V 20 amp circuit
  • Wide Operating range of 60ºF-110ºF
  • ETL and CETL listed to UL and CSA standards
  • Includes counterflow coaxial condenser coil with automatic water regulating valve.
  • Multi-function microprocessor control with a large, easy-to-read LCD display
  • Easy-touch control pads make changing system settings a snap.
  • Self Diagnostics that include audible alarm and LCD visual display readout for system fault conditions
  • Input/Output Alarm Contacts for connection to building systems
  • Internal high lift condensate pumps and a 5- gallon reservoir tank for total condensate flexibility.
  • Condensate overflow protection
  • Three fan speeds
  • Auto speed- automatically sets fan speed based on heat load demand (not available on single speed models)
  • Thermostatic Expansion Valve
  • Heavy duty compressor with automatic restart and short cycle protection.
  • Motors and compressors have overload protection.
  • High-pressure safety with manual reset.
  • Low-pressure safety with automatic reset.
  • Automatic freeze protection using hot gas bypass and fan cycling.
  • Low ambient controls
  • Heavy-duty locking casters.
  • Rifle tube coils for efficient heat transfer.
  • Fully insulated, heavy duty galvanized steel cabinet with Kwikool’s exclusive E-Z Clean™ scratch-resistant attractive two-tone HammerCoat™ epoxy protective finish for optimum durability, efficiency, low maintenance and quiet operation.
  • Sight glass with moisture indicator.
  • Filter dryer for Moisture protection
  • Easy access Service Door
  • Shraeder service ports.
